Technical Features：
●Nominal Pressure: 300PSI
●Conforms: ANSI / AWWA C515 Standard
● Face to Face Standard : ASME B16.10
●Sizes: 2/", 3", 4", 5",6", 8", 10", 12"
●Flange Standard: ASME / ANSI B16.1 Class 125 or ASME I ANSIB16.42 Class 150 or BS EN1092-2 PN16 or GB/ T9113.1
●Approvals: FM, UL, CUL, NSF /ANSI 61 & NSF 1ANSI 372
●Maximum Working Pressure: 300PSI (Maximum Testing Pressure: 600PSI) conforms to UL262, ULC 1 ORD C262-92 , FM 1120 I 1130
●Maximum Working Temperature: 80°C 1176°F
●Coating Details: Epoxy coated interior and exterior by Electrostatic Spray or Coating upon request
●NPT plug on body with 2 operating nuts
●Certified lead-free by NSF/ANSI 61 & NSF I ANSI 372 is available
